MAGNDATA - Collection of Magnetic Structures

N	(x,y,z)	Seitz notation
1	x,y,z,+1	{ 1 \| 0 }
2	-x,-y,z,+1	{ 2₀₀₁ \| 0 }
3	-y,x,-z,+1	{ -4^-₀₀₁ \| 0 }
4	y,-x,-z,+1	{ -4⁺₀₀₁ \| 0 }
5	-x,y,-z,-1	{ 2'₀₁₀ \| 0 }
6	x,-y,-z,-1	{ 2'₁₀₀ \| 0 }
7	y,x,z,-1	{ m'_1-10 \| 0 }
8	-y,-x,z,-1	{ m'₁₁₀ \| 0 }
(1/2,1/2,1/2) + set click here to show and hide
9	x+1/2,y+1/2,z+1/2,+1	{ 1 \| 1/2 1/2 1/2 }
10	-x+1/2,-y+1/2,z+1/2,+1	{ 2₀₀₁ \| 1/2 1/2 1/2 }
11	-y+1/2,x+1/2,-z+1/2,+1	{ -4^-₀₀₁ \| 1/2 1/2 1/2 }
12	y+1/2,-x+1/2,-z+1/2,+1	{ -4⁺₀₀₁ \| 1/2 1/2 1/2 }
13	-x+1/2,y+1/2,-z+1/2,-1	{ 2'₀₁₀ \| 1/2 1/2 1/2 }
14	x+1/2,-y+1/2,-z+1/2,-1	{ 2'₁₀₀ \| 1/2 1/2 1/2 }
15	y+1/2,x+1/2,z+1/2,-1	{ m'_1-10 \| 1/2 1/2 1/2 }
16	-y+1/2,-x+1/2,z+1/2,-1	{ m'₁₁₀ \| 1/2 1/2 1/2 }

N	(x,y,z)	Seitz notation
1	x,y,z,+1	1
2	-x,-y,z,+1	2₀₀₁
3	-y,x,-z,+1	-4^-₀₀₁
4	y,-x,-z,+1	-4⁺₀₀₁
5	-x,y,-z,-1	2'₀₁₀
6	x,-y,-z,-1	2'₁₀₀
7	y,x,z,-1	m'_1-10
8	-y,-x,z,-1	m'₁₁₀

Magnetic atoms:

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Mn1	Mn	0.00000	0.00000	0.00000	2	0,0,m_z	0.0	0.0	1.84(15)	1.84
Mn2	Mn	0.31800	0.31800	0.31800	8	m_x,m_x,m_z	-0.02(10)	-0.02(10)	-0.83(14)	0.83
Mn3_1	Mn	0.35800	0.35800	0.03700	8	m_x,m_x,m_z	-0.08(9)	-0.08(9)	0.14(11)	0.18
Mn3_2	Mn	0.35800	0.03700	0.35800	16	m_x,m_y,m_z	-0.27(7)	-0.23(13)	0.07(13)	0.36
Mn4_1	Mn	0.08800	0.08800	0.28000	8	m_x,m_x,m_z	-0.04(11)	-0.04(11)	-0.42(11)	0.42
Mn4_2	Mn	0.08800	0.28000	0.08800	16	m_x,m_y,m_z	-0.19(8)	-0.15(8)	-0.06(10)	0.25

[Show all atoms in unit cell and their moment relations]

Positions and magnetic moments of all atoms in unit cell, with magnetic moment relations explicitly given:

Magnetic atoms:

Set of atoms in the unit cell related by symmetry with the magnetic atom Mn1:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.00000	0.00000	0.00000	0,0,m_z	0.00000	0.00000	1.84000
(1/2,1/2,1/2) + set click here to show and hide
2	0.50000	0.50000	0.50000	0,0,m_z	0.00000	0.00000	1.84000

Set of atoms in the unit cell related by symmetry with the magnetic atom Mn2:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.31800	0.31800	0.31800	m_x,m_x,m_z	-0.02000	-0.02000	-0.83000
2	0.68200	0.68200	0.31800	-m_x,-m_x,m_z	0.02000	0.02000	-0.83000
3	0.68200	0.31800	0.68200	m_x,-m_x,m_z	-0.02000	0.02000	-0.83000
4	0.31800	0.68200	0.68200	-m_x,m_x,m_z	0.02000	-0.02000	-0.83000
(1/2,1/2,1/2) + set click here to show and hide
5	0.81800	0.81800	0.81800	m_x,m_x,m_z	-0.02000	-0.02000	-0.83000
6	0.18200	0.18200	0.81800	-m_x,-m_x,m_z	0.02000	0.02000	-0.83000
7	0.18200	0.81800	0.18200	m_x,-m_x,m_z	-0.02000	0.02000	-0.83000
8	0.81800	0.18200	0.18200	-m_x,m_x,m_z	0.02000	-0.02000	-0.83000

Set of atoms in the unit cell related by symmetry with the magnetic atom Mn3_1:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.35800	0.35800	0.03700	m_x,m_x,m_z	-0.08000	-0.08000	0.14000
2	0.64200	0.64200	0.03700	-m_x,-m_x,m_z	0.08000	0.08000	0.14000
3	0.64200	0.35800	0.96300	m_x,-m_x,m_z	-0.08000	0.08000	0.14000
4	0.35800	0.64200	0.96300	-m_x,m_x,m_z	0.08000	-0.08000	0.14000
(1/2,1/2,1/2) + set click here to show and hide
5	0.85800	0.85800	0.53700	m_x,m_x,m_z	-0.08000	-0.08000	0.14000
6	0.14200	0.14200	0.53700	-m_x,-m_x,m_z	0.08000	0.08000	0.14000
7	0.14200	0.85800	0.46300	m_x,-m_x,m_z	-0.08000	0.08000	0.14000
8	0.85800	0.14200	0.46300	-m_x,m_x,m_z	0.08000	-0.08000	0.14000

Set of atoms in the unit cell related by symmetry with the magnetic atom Mn3_2:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.35800	0.03700	0.35800	m_x,m_y,m_z	-0.27000	-0.23000	0.07000
2	0.64200	0.96300	0.35800	-m_x,-m_y,m_z	0.27000	0.23000	0.07000
3	0.96300	0.35800	0.64200	m_y,-m_x,m_z	-0.23000	0.27000	0.07000
4	0.03700	0.64200	0.64200	-m_y,m_x,m_z	0.23000	-0.27000	0.07000
5	0.64200	0.03700	0.64200	m_x,-m_y,m_z	-0.27000	0.23000	0.07000
6	0.35800	0.96300	0.64200	-m_x,m_y,m_z	0.27000	-0.23000	0.07000
7	0.03700	0.35800	0.35800	m_y,m_x,m_z	-0.23000	-0.27000	0.07000
8	0.96300	0.64200	0.35800	-m_y,-m_x,m_z	0.23000	0.27000	0.07000
(1/2,1/2,1/2) + set click here to show and hide
9	0.85800	0.53700	0.85800	m_x,m_y,m_z	-0.27000	-0.23000	0.07000
10	0.14200	0.46300	0.85800	-m_x,-m_y,m_z	0.27000	0.23000	0.07000
11	0.46300	0.85800	0.14200	m_y,-m_x,m_z	-0.23000	0.27000	0.07000
12	0.53700	0.14200	0.14200	-m_y,m_x,m_z	0.23000	-0.27000	0.07000
13	0.14200	0.53700	0.14200	m_x,-m_y,m_z	-0.27000	0.23000	0.07000
14	0.85800	0.46300	0.14200	-m_x,m_y,m_z	0.27000	-0.23000	0.07000
15	0.53700	0.85800	0.85800	m_y,m_x,m_z	-0.23000	-0.27000	0.07000
16	0.46300	0.14200	0.85800	-m_y,-m_x,m_z	0.23000	0.27000	0.07000

Set of atoms in the unit cell related by symmetry with the magnetic atom Mn4_1:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.08800	0.08800	0.28000	m_x,m_x,m_z	-0.04000	-0.04000	-0.42000
2	0.91200	0.91200	0.28000	-m_x,-m_x,m_z	0.04000	0.04000	-0.42000
3	0.91200	0.08800	0.72000	m_x,-m_x,m_z	-0.04000	0.04000	-0.42000
4	0.08800	0.91200	0.72000	-m_x,m_x,m_z	0.04000	-0.04000	-0.42000
(1/2,1/2,1/2) + set click here to show and hide
5	0.58800	0.58800	0.78000	m_x,m_x,m_z	-0.04000	-0.04000	-0.42000
6	0.41200	0.41200	0.78000	-m_x,-m_x,m_z	0.04000	0.04000	-0.42000
7	0.41200	0.58800	0.22000	m_x,-m_x,m_z	-0.04000	0.04000	-0.42000
8	0.58800	0.41200	0.22000	-m_x,m_x,m_z	0.04000	-0.04000	-0.42000

Set of atoms in the unit cell related by symmetry with the magnetic atom Mn4_2:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.08800	0.28000	0.08800	m_x,m_y,m_z	-0.19000	-0.15000	-0.06000
2	0.91200	0.72000	0.08800	-m_x,-m_y,m_z	0.19000	0.15000	-0.06000
3	0.72000	0.08800	0.91200	m_y,-m_x,m_z	-0.15000	0.19000	-0.06000
4	0.28000	0.91200	0.91200	-m_y,m_x,m_z	0.15000	-0.19000	-0.06000
5	0.91200	0.28000	0.91200	m_x,-m_y,m_z	-0.19000	0.15000	-0.06000
6	0.08800	0.72000	0.91200	-m_x,m_y,m_z	0.19000	-0.15000	-0.06000
7	0.28000	0.08800	0.08800	m_y,m_x,m_z	-0.15000	-0.19000	-0.06000
8	0.72000	0.91200	0.08800	-m_y,-m_x,m_z	0.15000	0.19000	-0.06000
(1/2,1/2,1/2) + set click here to show and hide
9	0.58800	0.78000	0.58800	m_x,m_y,m_z	-0.19000	-0.15000	-0.06000
10	0.41200	0.22000	0.58800	-m_x,-m_y,m_z	0.19000	0.15000	-0.06000
11	0.22000	0.58800	0.41200	m_y,-m_x,m_z	-0.15000	0.19000	-0.06000
12	0.78000	0.41200	0.41200	-m_y,m_x,m_z	0.15000	-0.19000	-0.06000
13	0.41200	0.78000	0.41200	m_x,-m_y,m_z	-0.19000	0.15000	-0.06000
14	0.58800	0.22000	0.41200	-m_x,m_y,m_z	0.19000	-0.15000	-0.06000
15	0.78000	0.58800	0.58800	m_y,m_x,m_z	-0.15000	-0.19000	-0.06000
16	0.22000	0.41200	0.58800	-m_y,-m_x,m_z	0.15000	0.19000	-0.06000

[Hide]

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Mn1	Mn	0.00000	0.00000	0.00000	2	0,0,m_z	0.0	0.0	1.84(15)	1.84
Mn2	Mn	0.31800	0.31800	0.31800	8	m_x,m_x,m_z	-0.02(10)	-0.02(10)	-0.83(14)	0.83
Mn3_1	Mn	0.35800	0.35800	0.03700	8	m_x,m_x,m_z	-0.08(9)	-0.08(9)	0.14(11)	0.18
Mn3_2	Mn	0.35800	0.03700	0.35800	16	m_x,m_y,m_z	-0.27(7)	-0.23(13)	0.07(13)	0.36
Mn4_1	Mn	0.08800	0.08800	0.28000	8	m_x,m_x,m_z	-0.04(11)	-0.04(11)	-0.42(11)	0.42
Mn4_2	Mn	0.08800	0.28000	0.08800	16	m_x,m_y,m_z	-0.19(8)	-0.15(8)	-0.06(10)	0.25

[Show all magnetic atoms in unit cell and their moment relations]

Positions and magnetic moments of all atoms in unit cell, with magnetic moment relations explicitly given:
