MAGNDATA - Collection of Magnetic Structures

Symmetry operations of the magnetic space group in the setting used:

N	(x,y,z)	Seitz notation
1	x,y,z,+1	{ 1 \| 0 }
2	-z,-y,-x,+1	{ 2_-101 \| 0 }
3	-x,-y,-z,+1	{ -1 \| 0 }
4	z,y,x,+1	{ m_-101 \| 0 }
(0,1/4,3/4) + set click here to show and hide
5	x,y+1/4,z+3/4,+1	{ 1 \| 0 1/4 3/4 }
6	-z,-y+1/4,-x+3/4,+1	{ 2_-101 \| 0 1/4 3/4 }
7	-x,-y+1/4,-z+3/4,+1	{ -1 \| 0 1/4 3/4 }
8	z,y+1/4,x+3/4,+1	{ m_-101 \| 0 1/4 3/4 }
(0,1/2,1/2) + set click here to show and hide
9	x,y+1/2,z+1/2,+1	{ 1 \| 0 1/2 1/2 }
10	-z,-y+1/2,-x+1/2,+1	{ 2_-101 \| 0 1/2 1/2 }
11	-x,-y+1/2,-z+1/2,+1	{ -1 \| 0 1/2 1/2 }
12	z,y+1/2,x+1/2,+1	{ m_-101 \| 0 1/2 1/2 }
(0,3/4,1/4) + set click here to show and hide
13	x,y+3/4,z+1/4,+1	{ 1 \| 0 3/4 1/4 }
14	-z,-y+3/4,-x+1/4,+1	{ 2_-101 \| 0 3/4 1/4 }
15	-x,-y+3/4,-z+1/4,+1	{ -1 \| 0 3/4 1/4 }
16	z,y+3/4,x+1/4,+1	{ m_-101 \| 0 3/4 1/4 }
(1/4,0,3/4) + set click here to show and hide
17	x+1/4,y,z+3/4,+1	{ 1 \| 1/4 0 3/4 }
18	-z+1/4,-y,-x+3/4,+1	{ 2_-101 \| 1/4 0 3/4 }
19	-x+1/4,-y,-z+3/4,+1	{ -1 \| 1/4 0 3/4 }
20	z+1/4,y,x+3/4,+1	{ m_-101 \| 1/4 0 3/4 }
(1/4,1/4,1/2) + set click here to show and hide
21	x+1/4,y+1/4,z+1/2,+1	{ 1 \| 1/4 1/4 1/2 }
22	-z+1/4,-y+1/4,-x+1/2,+1	{ 2_-101 \| 1/4 1/4 1/2 }
23	-x+1/4,-y+1/4,-z+1/2,+1	{ -1 \| 1/4 1/4 1/2 }
24	z+1/4,y+1/4,x+1/2,+1	{ m_-101 \| 1/4 1/4 1/2 }
(1/4,1/2,1/4) + set click here to show and hide
25	x+1/4,y+1/2,z+1/4,+1	{ 1 \| 1/4 1/2 1/4 }
26	-z+1/4,-y+1/2,-x+1/4,+1	{ 2_-101 \| 1/4 1/2 1/4 }
27	-x+1/4,-y+1/2,-z+1/4,+1	{ -1 \| 1/4 1/2 1/4 }
28	z+1/4,y+1/2,x+1/4,+1	{ m_-101 \| 1/4 1/2 1/4 }
(1/4,3/4,0) + set click here to show and hide
29	x+1/4,y+3/4,z,+1	{ 1 \| 1/4 3/4 0 }
30	-z+1/4,-y+3/4,-x,+1	{ 2_-101 \| 1/4 3/4 0 }
31	-x+1/4,-y+3/4,-z,+1	{ -1 \| 1/4 3/4 0 }
32	z+1/4,y+3/4,x,+1	{ m_-101 \| 1/4 3/4 0 }
(1/2,0,1/2) + set click here to show and hide
33	x+1/2,y,z+1/2,+1	{ 1 \| 1/2 0 1/2 }
34	-z+1/2,-y,-x+1/2,+1	{ 2_-101 \| 1/2 0 1/2 }
35	-x+1/2,-y,-z+1/2,+1	{ -1 \| 1/2 0 1/2 }
36	z+1/2,y,x+1/2,+1	{ m_-101 \| 1/2 0 1/2 }
(1/2,1/4,1/4) + set click here to show and hide
37	x+1/2,y+1/4,z+1/4,+1	{ 1 \| 1/2 1/4 1/4 }
38	-z+1/2,-y+1/4,-x+1/4,+1	{ 2_-101 \| 1/2 1/4 1/4 }
39	-x+1/2,-y+1/4,-z+1/4,+1	{ -1 \| 1/2 1/4 1/4 }
40	z+1/2,y+1/4,x+1/4,+1	{ m_-101 \| 1/2 1/4 1/4 }
(1/2,1/2,0) + set click here to show and hide
41	x+1/2,y+1/2,z,+1	{ 1 \| 1/2 1/2 0 }
42	-z+1/2,-y+1/2,-x,+1	{ 2_-101 \| 1/2 1/2 0 }
43	-x+1/2,-y+1/2,-z,+1	{ -1 \| 1/2 1/2 0 }
44	z+1/2,y+1/2,x,+1	{ m_-101 \| 1/2 1/2 0 }
(1/2,3/4,3/4) + set click here to show and hide
45	x+1/2,y+3/4,z+3/4,+1	{ 1 \| 1/2 3/4 3/4 }
46	-z+1/2,-y+3/4,-x+3/4,+1	{ 2_-101 \| 1/2 3/4 3/4 }
47	-x+1/2,-y+3/4,-z+3/4,+1	{ -1 \| 1/2 3/4 3/4 }
48	z+1/2,y+3/4,x+3/4,+1	{ m_-101 \| 1/2 3/4 3/4 }
(3/4,0,1/4) + set click here to show and hide
49	x+3/4,y,z+1/4,+1	{ 1 \| 3/4 0 1/4 }
50	-z+3/4,-y,-x+1/4,+1	{ 2_-101 \| 3/4 0 1/4 }
51	-x+3/4,-y,-z+1/4,+1	{ -1 \| 3/4 0 1/4 }
52	z+3/4,y,x+1/4,+1	{ m_-101 \| 3/4 0 1/4 }
(3/4,1/4,0) + set click here to show and hide
53	x+3/4,y+1/4,z,+1	{ 1 \| 3/4 1/4 0 }
54	-z+3/4,-y+1/4,-x,+1	{ 2_-101 \| 3/4 1/4 0 }
55	-x+3/4,-y+1/4,-z,+1	{ -1 \| 3/4 1/4 0 }
56	z+3/4,y+1/4,x,+1	{ m_-101 \| 3/4 1/4 0 }
(3/4,1/2,3/4) + set click here to show and hide
57	x+3/4,y+1/2,z+3/4,+1	{ 1 \| 3/4 1/2 3/4 }
58	-z+3/4,-y+1/2,-x+3/4,+1	{ 2_-101 \| 3/4 1/2 3/4 }
59	-x+3/4,-y+1/2,-z+3/4,+1	{ -1 \| 3/4 1/2 3/4 }
60	z+3/4,y+1/2,x+3/4,+1	{ m_-101 \| 3/4 1/2 3/4 }
(3/4,3/4,1/2) + set click here to show and hide
61	x+3/4,y+3/4,z+1/2,+1	{ 1 \| 3/4 3/4 1/2 }
62	-z+3/4,-y+3/4,-x+1/2,+1	{ 2_-101 \| 3/4 3/4 1/2 }
63	-x+3/4,-y+3/4,-z+1/2,+1	{ -1 \| 3/4 3/4 1/2 }
64	z+3/4,y+3/4,x+1/2,+1	{ m_-101 \| 3/4 3/4 1/2 }
(0,3/4,3/4)' + set click here to show and hide
65	x,y+3/4,z+3/4,-1	{ 1' \| 0 3/4 3/4 }
66	-z,-y+3/4,-x+3/4,-1	{ 2'_-101 \| 0 3/4 3/4 }
67	-x,-y+3/4,-z+3/4,-1	{ -1' \| 0 3/4 3/4 }
68	z,y+3/4,x+3/4,-1	{ m'_-101 \| 0 3/4 3/4 }
(0,0,1/2)' + set click here to show and hide
69	x,y,z+1/2,-1	{ 1' \| 0 0 1/2 }
70	-z,-y,-x+1/2,-1	{ 2'_-101 \| 0 0 1/2 }
71	-x,-y,-z+1/2,-1	{ -1' \| 0 0 1/2 }
72	z,y,x+1/2,-1	{ m'_-101 \| 0 0 1/2 }
(0,1/4,1/4)' + set click here to show and hide
73	x,y+1/4,z+1/4,-1	{ 1' \| 0 1/4 1/4 }
74	-z,-y+1/4,-x+1/4,-1	{ 2'_-101 \| 0 1/4 1/4 }
75	-x,-y+1/4,-z+1/4,-1	{ -1' \| 0 1/4 1/4 }
76	z,y+1/4,x+1/4,-1	{ m'_-101 \| 0 1/4 1/4 }
(0,1/2,0)' + set click here to show and hide
77	x,y+1/2,z,-1	{ 1' \| 0 1/2 0 }
78	-z,-y+1/2,-x,-1	{ 2'_-101 \| 0 1/2 0 }
79	-x,-y+1/2,-z,-1	{ -1' \| 0 1/2 0 }
80	z,y+1/2,x,-1	{ m'_-101 \| 0 1/2 0 }
(1/4,3/4,1/2)' + set click here to show and hide
81	x+1/4,y+3/4,z+1/2,-1	{ 1' \| 1/4 3/4 1/2 }
82	-z+1/4,-y+3/4,-x+1/2,-1	{ 2'_-101 \| 1/4 3/4 1/2 }
83	-x+1/4,-y+3/4,-z+1/2,-1	{ -1' \| 1/4 3/4 1/2 }
84	z+1/4,y+3/4,x+1/2,-1	{ m'_-101 \| 1/4 3/4 1/2 }
(1/4,0,1/4)' + set click here to show and hide
85	x+1/4,y,z+1/4,-1	{ 1' \| 1/4 0 1/4 }
86	-z+1/4,-y,-x+1/4,-1	{ 2'_-101 \| 1/4 0 1/4 }
87	-x+1/4,-y,-z+1/4,-1	{ -1' \| 1/4 0 1/4 }
88	z+1/4,y,x+1/4,-1	{ m'_-101 \| 1/4 0 1/4 }
(1/4,1/4,0)' + set click here to show and hide
89	x+1/4,y+1/4,z,-1	{ 1' \| 1/4 1/4 0 }
90	-z+1/4,-y+1/4,-x,-1	{ 2'_-101 \| 1/4 1/4 0 }
91	-x+1/4,-y+1/4,-z,-1	{ -1' \| 1/4 1/4 0 }
92	z+1/4,y+1/4,x,-1	{ m'_-101 \| 1/4 1/4 0 }
(1/4,1/2,3/4)' + set click here to show and hide
93	x+1/4,y+1/2,z+3/4,-1	{ 1' \| 1/4 1/2 3/4 }
94	-z+1/4,-y+1/2,-x+3/4,-1	{ 2'_-101 \| 1/4 1/2 3/4 }
95	-x+1/4,-y+1/2,-z+3/4,-1	{ -1' \| 1/4 1/2 3/4 }
96	z+1/4,y+1/2,x+3/4,-1	{ m'_-101 \| 1/4 1/2 3/4 }
(1/2,3/4,1/4)' + set click here to show and hide
97	x+1/2,y+3/4,z+1/4,-1	{ 1' \| 1/2 3/4 1/4 }
98	-z+1/2,-y+3/4,-x+1/4,-1	{ 2'_-101 \| 1/2 3/4 1/4 }
99	-x+1/2,-y+3/4,-z+1/4,-1	{ -1' \| 1/2 3/4 1/4 }
100	z+1/2,y+3/4,x+1/4,-1	{ m'_-101 \| 1/2 3/4 1/4 }
(1/2,0,0)' + set click here to show and hide
101	x+1/2,y,z,-1	{ 1' \| 1/2 0 0 }
102	-z+1/2,-y,-x,-1	{ 2'_-101 \| 1/2 0 0 }
103	-x+1/2,-y,-z,-1	{ -1' \| 1/2 0 0 }
104	z+1/2,y,x,-1	{ m'_-101 \| 1/2 0 0 }
(1/2,1/4,3/4)' + set click here to show and hide
105	x+1/2,y+1/4,z+3/4,-1	{ 1' \| 1/2 1/4 3/4 }
106	-z+1/2,-y+1/4,-x+3/4,-1	{ 2'_-101 \| 1/2 1/4 3/4 }
107	-x+1/2,-y+1/4,-z+3/4,-1	{ -1' \| 1/2 1/4 3/4 }
108	z+1/2,y+1/4,x+3/4,-1	{ m'_-101 \| 1/2 1/4 3/4 }
(1/2,1/2,1/2)' + set click here to show and hide
109	x+1/2,y+1/2,z+1/2,-1	{ 1' \| 1/2 1/2 1/2 }
110	-z+1/2,-y+1/2,-x+1/2,-1	{ 2'_-101 \| 1/2 1/2 1/2 }
111	-x+1/2,-y+1/2,-z+1/2,-1	{ -1' \| 1/2 1/2 1/2 }
112	z+1/2,y+1/2,x+1/2,-1	{ m'_-101 \| 1/2 1/2 1/2 }
(3/4,3/4,0)' + set click here to show and hide
113	x+3/4,y+3/4,z,-1	{ 1' \| 3/4 3/4 0 }
114	-z+3/4,-y+3/4,-x,-1	{ 2'_-101 \| 3/4 3/4 0 }
115	-x+3/4,-y+3/4,-z,-1	{ -1' \| 3/4 3/4 0 }
116	z+3/4,y+3/4,x,-1	{ m'_-101 \| 3/4 3/4 0 }
(3/4,0,3/4)' + set click here to show and hide
117	x+3/4,y,z+3/4,-1	{ 1' \| 3/4 0 3/4 }
118	-z+3/4,-y,-x+3/4,-1	{ 2'_-101 \| 3/4 0 3/4 }
119	-x+3/4,-y,-z+3/4,-1	{ -1' \| 3/4 0 3/4 }
120	z+3/4,y,x+3/4,-1	{ m'_-101 \| 3/4 0 3/4 }
(3/4,1/4,1/2)' + set click here to show and hide
121	x+3/4,y+1/4,z+1/2,-1	{ 1' \| 3/4 1/4 1/2 }
122	-z+3/4,-y+1/4,-x+1/2,-1	{ 2'_-101 \| 3/4 1/4 1/2 }
123	-x+3/4,-y+1/4,-z+1/2,-1	{ -1' \| 3/4 1/4 1/2 }
124	z+3/4,y+1/4,x+1/2,-1	{ m'_-101 \| 3/4 1/4 1/2 }
(3/4,1/2,1/4)' + set click here to show and hide
125	x+3/4,y+1/2,z+1/4,-1	{ 1' \| 3/4 1/2 1/4 }
126	-z+3/4,-y+1/2,-x+1/4,-1	{ 2'_-101 \| 3/4 1/2 1/4 }
127	-x+3/4,-y+1/2,-z+1/4,-1	{ -1' \| 3/4 1/2 1/4 }
128	z+3/4,y+1/2,x+1/4,-1	{ m'_-101 \| 3/4 1/2 1/4 }

[Hide]

N	(x,y,z)	Seitz notation
1	x,y,z,+1	1
2	-z,-y,-x,+1	2_-101
3	-x,-y,-z,+1	-1
4	z,y,x,+1	m_-101
1' + set click here to show and hide
5	x,y,z,-1	1'
6	-z,-y,-x,-1	2'_-101
7	-x,-y,-z,-1	-1'
8	z,y,x,-1	m'_-101

Magnetic atoms:

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_x	M_z	\|M\|
Ni1_1	Ni	0.25000	0.25000	0.25000	32	0,0,0	0.0	0.0	0.00
Ni1_2	Ni	0.12500	0.37500	0.00000	64	m_x,m_y,m_z	0.92	-0.92	1.30
Ni1_3	Ni	0.37500	0.00000	0.12500	32	m_x,0,-m_x	0.92	-0.92	1.30

Non-magnetic atoms:

Label	Atom type	x	y	z	Multiplicity
Ge1	Ge	0.06250	0.06250	0.06250	64
O1_1	O	0.12520	0.12520	0.12520	64
O1_2	O	0.24980	0.99980	0.37520	128
O1_3	O	0.99980	0.37520	0.24980	64

[Show all atoms in unit cell and their moment relations]

Positions and magnetic moments of all atoms in unit cell, with magnetic moment relations explicitly given:

Magnetic atoms:

Set of atoms in the unit cell related by symmetry with the magnetic atom Ni1_1:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.25000	0.25000	0.25000	0,0,0	0.00000	0.00000	0.00000
(0,1/4,3/4) + set click here to show and hide
2	0.25000	0.50000	0.00000	0,0,0	0.00000	0.00000	0.00000
(0,1/2,1/2) + set click here to show and hide
3	0.25000	0.75000	0.75000	0,0,0	0.00000	0.00000	0.00000
(0,3/4,1/4) + set click here to show and hide
4	0.25000	0.00000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/4,0,3/4) + set click here to show and hide
5	0.50000	0.25000	0.00000	0,0,0	0.00000	0.00000	0.00000
(1/4,1/4,1/2) + set click here to show and hide
6	0.50000	0.50000	0.75000	0,0,0	0.00000	0.00000	0.00000
(1/4,1/2,1/4) + set click here to show and hide
7	0.50000	0.75000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/4,3/4,0) + set click here to show and hide
8	0.50000	0.00000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/2,0,1/2) + set click here to show and hide
9	0.75000	0.25000	0.75000	0,0,0	0.00000	0.00000	0.00000
(1/2,1/4,1/4) + set click here to show and hide
10	0.75000	0.50000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/2,1/2,0) + set click here to show and hide
11	0.75000	0.75000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/2,3/4,3/4) + set click here to show and hide
12	0.75000	0.00000	0.00000	0,0,0	0.00000	0.00000	0.00000
(3/4,0,1/4) + set click here to show and hide
13	0.00000	0.25000	0.50000	0,0,0	0.00000	0.00000	0.00000
(3/4,1/4,0) + set click here to show and hide
14	0.00000	0.50000	0.25000	0,0,0	0.00000	0.00000	0.00000
(3/4,1/2,3/4) + set click here to show and hide
15	0.00000	0.75000	0.00000	0,0,0	0.00000	0.00000	0.00000
(3/4,3/4,1/2) + set click here to show and hide
16	0.00000	0.00000	0.75000	0,0,0	0.00000	0.00000	0.00000
(0,3/4,3/4)' + set click here to show and hide
17	0.25000	0.00000	0.00000	0,0,0	0.00000	0.00000	0.00000
(0,0,1/2)' + set click here to show and hide
18	0.25000	0.25000	0.75000	0,0,0	0.00000	0.00000	0.00000
(0,1/4,1/4)' + set click here to show and hide
19	0.25000	0.50000	0.50000	0,0,0	0.00000	0.00000	0.00000
(0,1/2,0)' + set click here to show and hide
20	0.25000	0.75000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/4,3/4,1/2)' + set click here to show and hide
21	0.50000	0.00000	0.75000	0,0,0	0.00000	0.00000	0.00000
(1/4,0,1/4)' + set click here to show and hide
22	0.50000	0.25000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/4,1/4,0)' + set click here to show and hide
23	0.50000	0.50000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/4,1/2,3/4)' + set click here to show and hide
24	0.50000	0.75000	0.00000	0,0,0	0.00000	0.00000	0.00000
(1/2,3/4,1/4)' + set click here to show and hide
25	0.75000	0.00000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/2,0,0)' + set click here to show and hide
26	0.75000	0.25000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/2,1/4,3/4)' + set click here to show and hide
27	0.75000	0.50000	0.00000	0,0,0	0.00000	0.00000	0.00000
(1/2,1/2,1/2)' + set click here to show and hide
28	0.75000	0.75000	0.75000	0,0,0	0.00000	0.00000	0.00000
(3/4,3/4,0)' + set click here to show and hide
29	0.00000	0.00000	0.25000	0,0,0	0.00000	0.00000	0.00000
(3/4,0,3/4)' + set click here to show and hide
30	0.00000	0.25000	0.00000	0,0,0	0.00000	0.00000	0.00000
(3/4,1/4,1/2)' + set click here to show and hide
31	0.00000	0.50000	0.75000	0,0,0	0.00000	0.00000	0.00000
(3/4,1/2,1/4)' + set click here to show and hide
32	0.00000	0.75000	0.50000	0,0,0	0.00000	0.00000	0.00000

Set of atoms in the unit cell related by symmetry with the magnetic atom Ni1_2:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.12500	0.37500	0.00000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
2	0.00000	0.62500	0.87500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(0,1/4,3/4) + set click here to show and hide
3	0.12500	0.62500	0.75000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
4	0.00000	0.87500	0.62500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(0,1/2,1/2) + set click here to show and hide
5	0.12500	0.87500	0.50000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
6	0.00000	0.12500	0.37500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(0,3/4,1/4) + set click here to show and hide
7	0.12500	0.12500	0.25000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
8	0.00000	0.37500	0.12500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/4,0,3/4) + set click here to show and hide
9	0.37500	0.37500	0.75000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
10	0.25000	0.62500	0.62500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/4,1/4,1/2) + set click here to show and hide
11	0.37500	0.62500	0.50000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
12	0.25000	0.87500	0.37500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/4,1/2,1/4) + set click here to show and hide
13	0.37500	0.87500	0.25000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
14	0.25000	0.12500	0.12500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/4,3/4,0) + set click here to show and hide
15	0.37500	0.12500	0.00000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
16	0.25000	0.37500	0.87500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/2,0,1/2) + set click here to show and hide
17	0.62500	0.37500	0.50000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
18	0.50000	0.62500	0.37500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/2,1/4,1/4) + set click here to show and hide
19	0.62500	0.62500	0.25000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
20	0.50000	0.87500	0.12500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/2,1/2,0) + set click here to show and hide
21	0.62500	0.87500	0.00000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
22	0.50000	0.12500	0.87500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/2,3/4,3/4) + set click here to show and hide
23	0.62500	0.12500	0.75000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
24	0.50000	0.37500	0.62500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(3/4,0,1/4) + set click here to show and hide
25	0.87500	0.37500	0.25000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
26	0.75000	0.62500	0.12500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(3/4,1/4,0) + set click here to show and hide
27	0.87500	0.62500	0.00000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
28	0.75000	0.87500	0.87500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(3/4,1/2,3/4) + set click here to show and hide
29	0.87500	0.87500	0.75000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
30	0.75000	0.12500	0.62500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(3/4,3/4,1/2) + set click here to show and hide
31	0.87500	0.12500	0.50000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
32	0.75000	0.37500	0.37500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(0,3/4,3/4)' + set click here to show and hide
33	0.12500	0.12500	0.75000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
34	0.00000	0.37500	0.62500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(0,0,1/2)' + set click here to show and hide
35	0.12500	0.37500	0.50000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
36	0.00000	0.62500	0.37500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(0,1/4,1/4)' + set click here to show and hide
37	0.12500	0.62500	0.25000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
38	0.00000	0.87500	0.12500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(0,1/2,0)' + set click here to show and hide
39	0.12500	0.87500	0.00000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
40	0.00000	0.12500	0.87500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/4,3/4,1/2)' + set click here to show and hide
41	0.37500	0.12500	0.50000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
42	0.25000	0.37500	0.37500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/4,0,1/4)' + set click here to show and hide
43	0.37500	0.37500	0.25000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
44	0.25000	0.62500	0.12500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/4,1/4,0)' + set click here to show and hide
45	0.37500	0.62500	0.00000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
46	0.25000	0.87500	0.87500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/4,1/2,3/4)' + set click here to show and hide
47	0.37500	0.87500	0.75000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
48	0.25000	0.12500	0.62500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/2,3/4,1/4)' + set click here to show and hide
49	0.62500	0.12500	0.25000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
50	0.50000	0.37500	0.12500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/2,0,0)' + set click here to show and hide
51	0.62500	0.37500	0.00000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
52	0.50000	0.62500	0.87500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/2,1/4,3/4)' + set click here to show and hide
53	0.62500	0.62500	0.75000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
54	0.50000	0.87500	0.62500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/2,1/2,1/2)' + set click here to show and hide
55	0.62500	0.87500	0.50000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
56	0.50000	0.12500	0.37500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(3/4,3/4,0)' + set click here to show and hide
57	0.87500	0.12500	0.00000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
58	0.75000	0.37500	0.87500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(3/4,0,3/4)' + set click here to show and hide
59	0.87500	0.37500	0.75000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
60	0.75000	0.62500	0.62500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(3/4,1/4,1/2)' + set click here to show and hide
61	0.87500	0.62500	0.50000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
62	0.75000	0.87500	0.37500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(3/4,1/2,1/4)' + set click here to show and hide
63	0.87500	0.87500	0.25000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
64	0.75000	0.12500	0.12500	m_z,m_y,m_x	-0.92000	0.00000	0.92000

Set of atoms in the unit cell related by symmetry with the magnetic atom Ni1_3:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.37500	0.00000	0.12500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(0,1/4,3/4) + set click here to show and hide
2	0.37500	0.25000	0.87500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(0,1/2,1/2) + set click here to show and hide
3	0.37500	0.50000	0.62500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(0,3/4,1/4) + set click here to show and hide
4	0.37500	0.75000	0.37500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/4,0,3/4) + set click here to show and hide
5	0.62500	0.00000	0.87500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/4,1/4,1/2) + set click here to show and hide
6	0.62500	0.25000	0.62500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/4,1/2,1/4) + set click here to show and hide
7	0.62500	0.50000	0.37500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/4,3/4,0) + set click here to show and hide
8	0.62500	0.75000	0.12500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/2,0,1/2) + set click here to show and hide
9	0.87500	0.00000	0.62500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/2,1/4,1/4) + set click here to show and hide
10	0.87500	0.25000	0.37500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/2,1/2,0) + set click here to show and hide
11	0.87500	0.50000	0.12500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/2,3/4,3/4) + set click here to show and hide
12	0.87500	0.75000	0.87500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(3/4,0,1/4) + set click here to show and hide
13	0.12500	0.00000	0.37500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(3/4,1/4,0) + set click here to show and hide
14	0.12500	0.25000	0.12500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(3/4,1/2,3/4) + set click here to show and hide
15	0.12500	0.50000	0.87500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(3/4,3/4,1/2) + set click here to show and hide
16	0.12500	0.75000	0.62500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(0,3/4,3/4)' + set click here to show and hide
17	0.37500	0.75000	0.87500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(0,0,1/2)' + set click here to show and hide
18	0.37500	0.00000	0.62500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(0,1/4,1/4)' + set click here to show and hide
19	0.37500	0.25000	0.37500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(0,1/2,0)' + set click here to show and hide
20	0.37500	0.50000	0.12500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/4,3/4,1/2)' + set click here to show and hide
21	0.62500	0.75000	0.62500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/4,0,1/4)' + set click here to show and hide
22	0.62500	0.00000	0.37500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/4,1/4,0)' + set click here to show and hide
23	0.62500	0.25000	0.12500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/4,1/2,3/4)' + set click here to show and hide
24	0.62500	0.50000	0.87500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/2,3/4,1/4)' + set click here to show and hide
25	0.87500	0.75000	0.37500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/2,0,0)' + set click here to show and hide
26	0.87500	0.00000	0.12500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/2,1/4,3/4)' + set click here to show and hide
27	0.87500	0.25000	0.87500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/2,1/2,1/2)' + set click here to show and hide
28	0.87500	0.50000	0.62500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(3/4,3/4,0)' + set click here to show and hide
29	0.12500	0.75000	0.12500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(3/4,0,3/4)' + set click here to show and hide
30	0.12500	0.00000	0.87500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(3/4,1/4,1/2)' + set click here to show and hide
31	0.12500	0.25000	0.62500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(3/4,1/2,1/4)' + set click here to show and hide
32	0.12500	0.50000	0.37500	-m_x,0,m_x	-0.92000	0.00000	0.92000

Non-magnetic atoms:

Set of atoms in the unit cell related by symmetry with the atom Ge1:

Atom	x	y	z
1	0.06250	0.06250	0.06250
2	0.93750	0.93750	0.93750
(0,1/4,3/4) + set click here to show and hide
3	0.06250	0.31250	0.81250
4	0.93750	0.18750	0.68750
(0,1/2,1/2) + set click here to show and hide
5	0.06250	0.56250	0.56250
6	0.93750	0.43750	0.43750
(0,3/4,1/4) + set click here to show and hide
7	0.06250	0.81250	0.31250
8	0.93750	0.68750	0.18750
(1/4,0,3/4) + set click here to show and hide
9	0.31250	0.06250	0.81250
10	0.18750	0.93750	0.68750
(1/4,1/4,1/2) + set click here to show and hide
11	0.31250	0.31250	0.56250
12	0.18750	0.18750	0.43750
(1/4,1/2,1/4) + set click here to show and hide
13	0.31250	0.56250	0.31250
14	0.18750	0.43750	0.18750
(1/4,3/4,0) + set click here to show and hide
15	0.31250	0.81250	0.06250
16	0.18750	0.68750	0.93750
(1/2,0,1/2) + set click here to show and hide
17	0.56250	0.06250	0.56250
18	0.43750	0.93750	0.43750
(1/2,1/4,1/4) + set click here to show and hide
19	0.56250	0.31250	0.31250
20	0.43750	0.18750	0.18750
(1/2,1/2,0) + set click here to show and hide
21	0.56250	0.56250	0.06250
22	0.43750	0.43750	0.93750
(1/2,3/4,3/4) + set click here to show and hide
23	0.56250	0.81250	0.81250
24	0.43750	0.68750	0.68750
(3/4,0,1/4) + set click here to show and hide
25	0.81250	0.06250	0.31250
26	0.68750	0.93750	0.18750
(3/4,1/4,0) + set click here to show and hide
27	0.81250	0.31250	0.06250
28	0.68750	0.18750	0.93750
(3/4,1/2,3/4) + set click here to show and hide
29	0.81250	0.56250	0.81250
30	0.68750	0.43750	0.68750
(3/4,3/4,1/2) + set click here to show and hide
31	0.81250	0.81250	0.56250
32	0.68750	0.68750	0.43750
(0,3/4,3/4)' + set click here to show and hide
33	0.06250	0.81250	0.81250
34	0.93750	0.68750	0.68750
(0,0,1/2)' + set click here to show and hide
35	0.06250	0.06250	0.56250
36	0.93750	0.93750	0.43750
(0,1/4,1/4)' + set click here to show and hide
37	0.06250	0.31250	0.31250
38	0.93750	0.18750	0.18750
(0,1/2,0)' + set click here to show and hide
39	0.06250	0.56250	0.06250
40	0.93750	0.43750	0.93750
(1/4,3/4,1/2)' + set click here to show and hide
41	0.31250	0.81250	0.56250
42	0.18750	0.68750	0.43750
(1/4,0,1/4)' + set click here to show and hide
43	0.31250	0.06250	0.31250
44	0.18750	0.93750	0.18750
(1/4,1/4,0)' + set click here to show and hide
45	0.31250	0.31250	0.06250
46	0.18750	0.18750	0.93750
(1/4,1/2,3/4)' + set click here to show and hide
47	0.31250	0.56250	0.81250
48	0.18750	0.43750	0.68750
(1/2,3/4,1/4)' + set click here to show and hide
49	0.56250	0.81250	0.31250
50	0.43750	0.68750	0.18750
(1/2,0,0)' + set click here to show and hide
51	0.56250	0.06250	0.06250
52	0.43750	0.93750	0.93750
(1/2,1/4,3/4)' + set click here to show and hide
53	0.56250	0.31250	0.81250
54	0.43750	0.18750	0.68750
(1/2,1/2,1/2)' + set click here to show and hide
55	0.56250	0.56250	0.56250
56	0.43750	0.43750	0.43750
(3/4,3/4,0)' + set click here to show and hide
57	0.81250	0.81250	0.06250
58	0.68750	0.68750	0.93750
(3/4,0,3/4)' + set click here to show and hide
59	0.81250	0.06250	0.81250
60	0.68750	0.93750	0.68750
(3/4,1/4,1/2)' + set click here to show and hide
61	0.81250	0.31250	0.56250
62	0.68750	0.18750	0.43750
(3/4,1/2,1/4)' + set click here to show and hide
63	0.81250	0.56250	0.31250
64	0.68750	0.43750	0.18750

Set of atoms in the unit cell related by symmetry with the atom O1_1:

Atom	x	y	z
1	0.12520	0.12520	0.12520
2	0.87480	0.87480	0.87480
(0,1/4,3/4) + set click here to show and hide
3	0.12520	0.37520	0.87520
4	0.87480	0.12480	0.62480
(0,1/2,1/2) + set click here to show and hide
5	0.12520	0.62520	0.62520
6	0.87480	0.37480	0.37480
(0,3/4,1/4) + set click here to show and hide
7	0.12520	0.87520	0.37520
8	0.87480	0.62480	0.12480
(1/4,0,3/4) + set click here to show and hide
9	0.37520	0.12520	0.87520
10	0.12480	0.87480	0.62480
(1/4,1/4,1/2) + set click here to show and hide
11	0.37520	0.37520	0.62520
12	0.12480	0.12480	0.37480
(1/4,1/2,1/4) + set click here to show and hide
13	0.37520	0.62520	0.37520
14	0.12480	0.37480	0.12480
(1/4,3/4,0) + set click here to show and hide
15	0.37520	0.87520	0.12520
16	0.12480	0.62480	0.87480
(1/2,0,1/2) + set click here to show and hide
17	0.62520	0.12520	0.62520
18	0.37480	0.87480	0.37480
(1/2,1/4,1/4) + set click here to show and hide
19	0.62520	0.37520	0.37520
20	0.37480	0.12480	0.12480
(1/2,1/2,0) + set click here to show and hide
21	0.62520	0.62520	0.12520
22	0.37480	0.37480	0.87480
(1/2,3/4,3/4) + set click here to show and hide
23	0.62520	0.87520	0.87520
24	0.37480	0.62480	0.62480
(3/4,0,1/4) + set click here to show and hide
25	0.87520	0.12520	0.37520
26	0.62480	0.87480	0.12480
(3/4,1/4,0) + set click here to show and hide
27	0.87520	0.37520	0.12520
28	0.62480	0.12480	0.87480
(3/4,1/2,3/4) + set click here to show and hide
29	0.87520	0.62520	0.87520
30	0.62480	0.37480	0.62480
(3/4,3/4,1/2) + set click here to show and hide
31	0.87520	0.87520	0.62520
32	0.62480	0.62480	0.37480
(0,3/4,3/4)' + set click here to show and hide
33	0.12520	0.87520	0.87520
34	0.87480	0.62480	0.62480
(0,0,1/2)' + set click here to show and hide
35	0.12520	0.12520	0.62520
36	0.87480	0.87480	0.37480
(0,1/4,1/4)' + set click here to show and hide
37	0.12520	0.37520	0.37520
38	0.87480	0.12480	0.12480
(0,1/2,0)' + set click here to show and hide
39	0.12520	0.62520	0.12520
40	0.87480	0.37480	0.87480
(1/4,3/4,1/2)' + set click here to show and hide
41	0.37520	0.87520	0.62520
42	0.12480	0.62480	0.37480
(1/4,0,1/4)' + set click here to show and hide
43	0.37520	0.12520	0.37520
44	0.12480	0.87480	0.12480
(1/4,1/4,0)' + set click here to show and hide
45	0.37520	0.37520	0.12520
46	0.12480	0.12480	0.87480
(1/4,1/2,3/4)' + set click here to show and hide
47	0.37520	0.62520	0.87520
48	0.12480	0.37480	0.62480
(1/2,3/4,1/4)' + set click here to show and hide
49	0.62520	0.87520	0.37520
50	0.37480	0.62480	0.12480
(1/2,0,0)' + set click here to show and hide
51	0.62520	0.12520	0.12520
52	0.37480	0.87480	0.87480
(1/2,1/4,3/4)' + set click here to show and hide
53	0.62520	0.37520	0.87520
54	0.37480	0.12480	0.62480
(1/2,1/2,1/2)' + set click here to show and hide
55	0.62520	0.62520	0.62520
56	0.37480	0.37480	0.37480
(3/4,3/4,0)' + set click here to show and hide
57	0.87520	0.87520	0.12520
58	0.62480	0.62480	0.87480
(3/4,0,3/4)' + set click here to show and hide
59	0.87520	0.12520	0.87520
60	0.62480	0.87480	0.62480
(3/4,1/4,1/2)' + set click here to show and hide
61	0.87520	0.37520	0.62520
62	0.62480	0.12480	0.37480
(3/4,1/2,1/4)' + set click here to show and hide
63	0.87520	0.62520	0.37520
64	0.62480	0.37480	0.12480

Set of atoms in the unit cell related by symmetry with the atom O1_2:

Atom	x	y	z
1	0.24980	0.99980	0.37520
2	0.62480	0.00020	0.75020
3	0.75020	0.00020	0.62480
4	0.37520	0.99980	0.24980
(0,1/4,3/4) + set click here to show and hide
5	0.24980	0.24980	0.12520
6	0.62480	0.25020	0.50020
7	0.75020	0.25020	0.37480
8	0.37520	0.24980	0.99980
(0,1/2,1/2) + set click here to show and hide
9	0.24980	0.49980	0.87520
10	0.62480	0.50020	0.25020
11	0.75020	0.50020	0.12480
12	0.37520	0.49980	0.74980
(0,3/4,1/4) + set click here to show and hide
13	0.24980	0.74980	0.62520
14	0.62480	0.75020	0.00020
15	0.75020	0.75020	0.87480
16	0.37520	0.74980	0.49980
(1/4,0,3/4) + set click here to show and hide
17	0.49980	0.99980	0.12520
18	0.87480	0.00020	0.50020
19	0.00020	0.00020	0.37480
20	0.62520	0.99980	0.99980
(1/4,1/4,1/2) + set click here to show and hide
21	0.49980	0.24980	0.87520
22	0.87480	0.25020	0.25020
23	0.00020	0.25020	0.12480
24	0.62520	0.24980	0.74980
(1/4,1/2,1/4) + set click here to show and hide
25	0.49980	0.49980	0.62520
26	0.87480	0.50020	0.00020
27	0.00020	0.50020	0.87480
28	0.62520	0.49980	0.49980
(1/4,3/4,0) + set click here to show and hide
29	0.49980	0.74980	0.37520
30	0.87480	0.75020	0.75020
31	0.00020	0.75020	0.62480
32	0.62520	0.74980	0.24980
(1/2,0,1/2) + set click here to show and hide
33	0.74980	0.99980	0.87520
34	0.12480	0.00020	0.25020
35	0.25020	0.00020	0.12480
36	0.87520	0.99980	0.74980
(1/2,1/4,1/4) + set click here to show and hide
37	0.74980	0.24980	0.62520
38	0.12480	0.25020	0.00020
39	0.25020	0.25020	0.87480
40	0.87520	0.24980	0.49980
(1/2,1/2,0) + set click here to show and hide
41	0.74980	0.49980	0.37520
42	0.12480	0.50020	0.75020
43	0.25020	0.50020	0.62480
44	0.87520	0.49980	0.24980
(1/2,3/4,3/4) + set click here to show and hide
45	0.74980	0.74980	0.12520
46	0.12480	0.75020	0.50020
47	0.25020	0.75020	0.37480
48	0.87520	0.74980	0.99980
(3/4,0,1/4) + set click here to show and hide
49	0.99980	0.99980	0.62520
50	0.37480	0.00020	0.00020
51	0.50020	0.00020	0.87480
52	0.12520	0.99980	0.49980
(3/4,1/4,0) + set click here to show and hide
53	0.99980	0.24980	0.37520
54	0.37480	0.25020	0.75020
55	0.50020	0.25020	0.62480
56	0.12520	0.24980	0.24980
(3/4,1/2,3/4) + set click here to show and hide
57	0.99980	0.49980	0.12520
58	0.37480	0.50020	0.50020
59	0.50020	0.50020	0.37480
60	0.12520	0.49980	0.99980
(3/4,3/4,1/2) + set click here to show and hide
61	0.99980	0.74980	0.87520
62	0.37480	0.75020	0.25020
63	0.50020	0.75020	0.12480
64	0.12520	0.74980	0.74980
(0,3/4,3/4)' + set click here to show and hide
65	0.24980	0.74980	0.12520
66	0.62480	0.75020	0.50020
67	0.75020	0.75020	0.37480
68	0.37520	0.74980	0.99980
(0,0,1/2)' + set click here to show and hide
69	0.24980	0.99980	0.87520
70	0.62480	0.00020	0.25020
71	0.75020	0.00020	0.12480
72	0.37520	0.99980	0.74980
(0,1/4,1/4)' + set click here to show and hide
73	0.24980	0.24980	0.62520
74	0.62480	0.25020	0.00020
75	0.75020	0.25020	0.87480
76	0.37520	0.24980	0.49980
(0,1/2,0)' + set click here to show and hide
77	0.24980	0.49980	0.37520
78	0.62480	0.50020	0.75020
79	0.75020	0.50020	0.62480
80	0.37520	0.49980	0.24980
(1/4,3/4,1/2)' + set click here to show and hide
81	0.49980	0.74980	0.87520
82	0.87480	0.75020	0.25020
83	0.00020	0.75020	0.12480
84	0.62520	0.74980	0.74980
(1/4,0,1/4)' + set click here to show and hide
85	0.49980	0.99980	0.62520
86	0.87480	0.00020	0.00020
87	0.00020	0.00020	0.87480
88	0.62520	0.99980	0.49980
(1/4,1/4,0)' + set click here to show and hide
89	0.49980	0.24980	0.37520
90	0.87480	0.25020	0.75020
91	0.00020	0.25020	0.62480
92	0.62520	0.24980	0.24980
(1/4,1/2,3/4)' + set click here to show and hide
93	0.49980	0.49980	0.12520
94	0.87480	0.50020	0.50020
95	0.00020	0.50020	0.37480
96	0.62520	0.49980	0.99980
(1/2,3/4,1/4)' + set click here to show and hide
97	0.74980	0.74980	0.62520
98	0.12480	0.75020	0.00020
99	0.25020	0.75020	0.87480
100	0.87520	0.74980	0.49980
(1/2,0,0)' + set click here to show and hide
101	0.74980	0.99980	0.37520
102	0.12480	0.00020	0.75020
103	0.25020	0.00020	0.62480
104	0.87520	0.99980	0.24980
(1/2,1/4,3/4)' + set click here to show and hide
105	0.74980	0.24980	0.12520
106	0.12480	0.25020	0.50020
107	0.25020	0.25020	0.37480
108	0.87520	0.24980	0.99980
(1/2,1/2,1/2)' + set click here to show and hide
109	0.74980	0.49980	0.87520
110	0.12480	0.50020	0.25020
111	0.25020	0.50020	0.12480
112	0.87520	0.49980	0.74980
(3/4,3/4,0)' + set click here to show and hide
113	0.99980	0.74980	0.37520
114	0.37480	0.75020	0.75020
115	0.50020	0.75020	0.62480
116	0.12520	0.74980	0.24980
(3/4,0,3/4)' + set click here to show and hide
117	0.99980	0.99980	0.12520
118	0.37480	0.00020	0.50020
119	0.50020	0.00020	0.37480
120	0.12520	0.99980	0.99980
(3/4,1/4,1/2)' + set click here to show and hide
121	0.99980	0.24980	0.87520
122	0.37480	0.25020	0.25020
123	0.50020	0.25020	0.12480
124	0.12520	0.24980	0.74980
(3/4,1/2,1/4)' + set click here to show and hide
125	0.99980	0.49980	0.62520
126	0.37480	0.50020	0.00020
127	0.50020	0.50020	0.87480
128	0.12520	0.49980	0.49980

Set of atoms in the unit cell related by symmetry with the atom O1_3:

Atom	x	y	z
1	0.99980	0.37520	0.24980
2	0.75020	0.62480	0.00020
(0,1/4,3/4) + set click here to show and hide
3	0.99980	0.62520	0.99980
4	0.75020	0.87480	0.75020
(0,1/2,1/2) + set click here to show and hide
5	0.99980	0.87520	0.74980
6	0.75020	0.12480	0.50020
(0,3/4,1/4) + set click here to show and hide
7	0.99980	0.12520	0.49980
8	0.75020	0.37480	0.25020
(1/4,0,3/4) + set click here to show and hide
9	0.24980	0.37520	0.99980
10	0.00020	0.62480	0.75020
(1/4,1/4,1/2) + set click here to show and hide
11	0.24980	0.62520	0.74980
12	0.00020	0.87480	0.50020
(1/4,1/2,1/4) + set click here to show and hide
13	0.24980	0.87520	0.49980
14	0.00020	0.12480	0.25020
(1/4,3/4,0) + set click here to show and hide
15	0.24980	0.12520	0.24980
16	0.00020	0.37480	0.00020
(1/2,0,1/2) + set click here to show and hide
17	0.49980	0.37520	0.74980
18	0.25020	0.62480	0.50020
(1/2,1/4,1/4) + set click here to show and hide
19	0.49980	0.62520	0.49980
20	0.25020	0.87480	0.25020
(1/2,1/2,0) + set click here to show and hide
21	0.49980	0.87520	0.24980
22	0.25020	0.12480	0.00020
(1/2,3/4,3/4) + set click here to show and hide
23	0.49980	0.12520	0.99980
24	0.25020	0.37480	0.75020
(3/4,0,1/4) + set click here to show and hide
25	0.74980	0.37520	0.49980
26	0.50020	0.62480	0.25020
(3/4,1/4,0) + set click here to show and hide
27	0.74980	0.62520	0.24980
28	0.50020	0.87480	0.00020
(3/4,1/2,3/4) + set click here to show and hide
29	0.74980	0.87520	0.99980
30	0.50020	0.12480	0.75020
(3/4,3/4,1/2) + set click here to show and hide
31	0.74980	0.12520	0.74980
32	0.50020	0.37480	0.50020
(0,3/4,3/4)' + set click here to show and hide
33	0.99980	0.12520	0.99980
34	0.75020	0.37480	0.75020
(0,0,1/2)' + set click here to show and hide
35	0.99980	0.37520	0.74980
36	0.75020	0.62480	0.50020
(0,1/4,1/4)' + set click here to show and hide
37	0.99980	0.62520	0.49980
38	0.75020	0.87480	0.25020
(0,1/2,0)' + set click here to show and hide
39	0.99980	0.87520	0.24980
40	0.75020	0.12480	0.00020
(1/4,3/4,1/2)' + set click here to show and hide
41	0.24980	0.12520	0.74980
42	0.00020	0.37480	0.50020
(1/4,0,1/4)' + set click here to show and hide
43	0.24980	0.37520	0.49980
44	0.00020	0.62480	0.25020
(1/4,1/4,0)' + set click here to show and hide
45	0.24980	0.62520	0.24980
46	0.00020	0.87480	0.00020
(1/4,1/2,3/4)' + set click here to show and hide
47	0.24980	0.87520	0.99980
48	0.00020	0.12480	0.75020
(1/2,3/4,1/4)' + set click here to show and hide
49	0.49980	0.12520	0.49980
50	0.25020	0.37480	0.25020
(1/2,0,0)' + set click here to show and hide
51	0.49980	0.37520	0.24980
52	0.25020	0.62480	0.00020
(1/2,1/4,3/4)' + set click here to show and hide
53	0.49980	0.62520	0.99980
54	0.25020	0.87480	0.75020
(1/2,1/2,1/2)' + set click here to show and hide
55	0.49980	0.87520	0.74980
56	0.25020	0.12480	0.50020
(3/4,3/4,0)' + set click here to show and hide
57	0.74980	0.12520	0.24980
58	0.50020	0.37480	0.00020
(3/4,0,3/4)' + set click here to show and hide
59	0.74980	0.37520	0.99980
60	0.50020	0.62480	0.75020
(3/4,1/4,1/2)' + set click here to show and hide
61	0.74980	0.62520	0.74980
62	0.50020	0.87480	0.50020
(3/4,1/2,1/4)' + set click here to show and hide
63	0.74980	0.87520	0.49980
64	0.50020	0.12480	0.25020

[Hide]

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_x	M_z	\|M\|
Ni1_1	Ni	0.25000	0.25000	0.25000	32	0,0,0	0.0	0.0	0.00
Ni1_2	Ni	0.12500	0.37500	0.00000	64	m_x,m_y,m_z	0.92	-0.92	1.30
Ni1_3	Ni	0.37500	0.00000	0.12500	32	m_x,0,-m_x	0.92	-0.92	1.30

[Show all magnetic atoms in unit cell and their moment relations]

Positions and magnetic moments of all atoms in unit cell, with magnetic moment relations explicitly given:

Set of atoms in the unit cell related by symmetry with the magnetic atom Ni1_1:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.25000	0.25000	0.25000	0,0,0	0.00000	0.00000	0.00000
(0,1/4,3/4) + set click here to show and hide
2	0.25000	0.50000	0.00000	0,0,0	0.00000	0.00000	0.00000
(0,1/2,1/2) + set click here to show and hide
3	0.25000	0.75000	0.75000	0,0,0	0.00000	0.00000	0.00000
(0,3/4,1/4) + set click here to show and hide
4	0.25000	0.00000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/4,0,3/4) + set click here to show and hide
5	0.50000	0.25000	0.00000	0,0,0	0.00000	0.00000	0.00000
(1/4,1/4,1/2) + set click here to show and hide
6	0.50000	0.50000	0.75000	0,0,0	0.00000	0.00000	0.00000
(1/4,1/2,1/4) + set click here to show and hide
7	0.50000	0.75000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/4,3/4,0) + set click here to show and hide
8	0.50000	0.00000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/2,0,1/2) + set click here to show and hide
9	0.75000	0.25000	0.75000	0,0,0	0.00000	0.00000	0.00000
(1/2,1/4,1/4) + set click here to show and hide
10	0.75000	0.50000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/2,1/2,0) + set click here to show and hide
11	0.75000	0.75000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/2,3/4,3/4) + set click here to show and hide
12	0.75000	0.00000	0.00000	0,0,0	0.00000	0.00000	0.00000
(3/4,0,1/4) + set click here to show and hide
13	0.00000	0.25000	0.50000	0,0,0	0.00000	0.00000	0.00000
(3/4,1/4,0) + set click here to show and hide
14	0.00000	0.50000	0.25000	0,0,0	0.00000	0.00000	0.00000
(3/4,1/2,3/4) + set click here to show and hide
15	0.00000	0.75000	0.00000	0,0,0	0.00000	0.00000	0.00000
(3/4,3/4,1/2) + set click here to show and hide
16	0.00000	0.00000	0.75000	0,0,0	0.00000	0.00000	0.00000
(0,3/4,3/4)' + set click here to show and hide
17	0.25000	0.00000	0.00000	0,0,0	0.00000	0.00000	0.00000
(0,0,1/2)' + set click here to show and hide
18	0.25000	0.25000	0.75000	0,0,0	0.00000	0.00000	0.00000
(0,1/4,1/4)' + set click here to show and hide
19	0.25000	0.50000	0.50000	0,0,0	0.00000	0.00000	0.00000
(0,1/2,0)' + set click here to show and hide
20	0.25000	0.75000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/4,3/4,1/2)' + set click here to show and hide
21	0.50000	0.00000	0.75000	0,0,0	0.00000	0.00000	0.00000
(1/4,0,1/4)' + set click here to show and hide
22	0.50000	0.25000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/4,1/4,0)' + set click here to show and hide
23	0.50000	0.50000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/4,1/2,3/4)' + set click here to show and hide
24	0.50000	0.75000	0.00000	0,0,0	0.00000	0.00000	0.00000
(1/2,3/4,1/4)' + set click here to show and hide
25	0.75000	0.00000	0.50000	0,0,0	0.00000	0.00000	0.00000
(1/2,0,0)' + set click here to show and hide
26	0.75000	0.25000	0.25000	0,0,0	0.00000	0.00000	0.00000
(1/2,1/4,3/4)' + set click here to show and hide
27	0.75000	0.50000	0.00000	0,0,0	0.00000	0.00000	0.00000
(1/2,1/2,1/2)' + set click here to show and hide
28	0.75000	0.75000	0.75000	0,0,0	0.00000	0.00000	0.00000
(3/4,3/4,0)' + set click here to show and hide
29	0.00000	0.00000	0.25000	0,0,0	0.00000	0.00000	0.00000
(3/4,0,3/4)' + set click here to show and hide
30	0.00000	0.25000	0.00000	0,0,0	0.00000	0.00000	0.00000
(3/4,1/4,1/2)' + set click here to show and hide
31	0.00000	0.50000	0.75000	0,0,0	0.00000	0.00000	0.00000
(3/4,1/2,1/4)' + set click here to show and hide
32	0.00000	0.75000	0.50000	0,0,0	0.00000	0.00000	0.00000

Set of atoms in the unit cell related by symmetry with the magnetic atom Ni1_2:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.12500	0.37500	0.00000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
2	0.00000	0.62500	0.87500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(0,1/4,3/4) + set click here to show and hide
3	0.12500	0.62500	0.75000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
4	0.00000	0.87500	0.62500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(0,1/2,1/2) + set click here to show and hide
5	0.12500	0.87500	0.50000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
6	0.00000	0.12500	0.37500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(0,3/4,1/4) + set click here to show and hide
7	0.12500	0.12500	0.25000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
8	0.00000	0.37500	0.12500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/4,0,3/4) + set click here to show and hide
9	0.37500	0.37500	0.75000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
10	0.25000	0.62500	0.62500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/4,1/4,1/2) + set click here to show and hide
11	0.37500	0.62500	0.50000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
12	0.25000	0.87500	0.37500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/4,1/2,1/4) + set click here to show and hide
13	0.37500	0.87500	0.25000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
14	0.25000	0.12500	0.12500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/4,3/4,0) + set click here to show and hide
15	0.37500	0.12500	0.00000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
16	0.25000	0.37500	0.87500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/2,0,1/2) + set click here to show and hide
17	0.62500	0.37500	0.50000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
18	0.50000	0.62500	0.37500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/2,1/4,1/4) + set click here to show and hide
19	0.62500	0.62500	0.25000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
20	0.50000	0.87500	0.12500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/2,1/2,0) + set click here to show and hide
21	0.62500	0.87500	0.00000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
22	0.50000	0.12500	0.87500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(1/2,3/4,3/4) + set click here to show and hide
23	0.62500	0.12500	0.75000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
24	0.50000	0.37500	0.62500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(3/4,0,1/4) + set click here to show and hide
25	0.87500	0.37500	0.25000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
26	0.75000	0.62500	0.12500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(3/4,1/4,0) + set click here to show and hide
27	0.87500	0.62500	0.00000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
28	0.75000	0.87500	0.87500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(3/4,1/2,3/4) + set click here to show and hide
29	0.87500	0.87500	0.75000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
30	0.75000	0.12500	0.62500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(3/4,3/4,1/2) + set click here to show and hide
31	0.87500	0.12500	0.50000	m_x,m_y,m_z	0.92000	0.00000	-0.92000
32	0.75000	0.37500	0.37500	-m_z,-m_y,-m_x	0.92000	0.00000	-0.92000
(0,3/4,3/4)' + set click here to show and hide
33	0.12500	0.12500	0.75000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
34	0.00000	0.37500	0.62500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(0,0,1/2)' + set click here to show and hide
35	0.12500	0.37500	0.50000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
36	0.00000	0.62500	0.37500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(0,1/4,1/4)' + set click here to show and hide
37	0.12500	0.62500	0.25000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
38	0.00000	0.87500	0.12500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(0,1/2,0)' + set click here to show and hide
39	0.12500	0.87500	0.00000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
40	0.00000	0.12500	0.87500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/4,3/4,1/2)' + set click here to show and hide
41	0.37500	0.12500	0.50000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
42	0.25000	0.37500	0.37500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/4,0,1/4)' + set click here to show and hide
43	0.37500	0.37500	0.25000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
44	0.25000	0.62500	0.12500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/4,1/4,0)' + set click here to show and hide
45	0.37500	0.62500	0.00000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
46	0.25000	0.87500	0.87500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/4,1/2,3/4)' + set click here to show and hide
47	0.37500	0.87500	0.75000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
48	0.25000	0.12500	0.62500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/2,3/4,1/4)' + set click here to show and hide
49	0.62500	0.12500	0.25000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
50	0.50000	0.37500	0.12500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/2,0,0)' + set click here to show and hide
51	0.62500	0.37500	0.00000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
52	0.50000	0.62500	0.87500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/2,1/4,3/4)' + set click here to show and hide
53	0.62500	0.62500	0.75000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
54	0.50000	0.87500	0.62500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(1/2,1/2,1/2)' + set click here to show and hide
55	0.62500	0.87500	0.50000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
56	0.50000	0.12500	0.37500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(3/4,3/4,0)' + set click here to show and hide
57	0.87500	0.12500	0.00000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
58	0.75000	0.37500	0.87500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(3/4,0,3/4)' + set click here to show and hide
59	0.87500	0.37500	0.75000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
60	0.75000	0.62500	0.62500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(3/4,1/4,1/2)' + set click here to show and hide
61	0.87500	0.62500	0.50000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
62	0.75000	0.87500	0.37500	m_z,m_y,m_x	-0.92000	0.00000	0.92000
(3/4,1/2,1/4)' + set click here to show and hide
63	0.87500	0.87500	0.25000	-m_x,-m_y,-m_z	-0.92000	0.00000	0.92000
64	0.75000	0.12500	0.12500	m_z,m_y,m_x	-0.92000	0.00000	0.92000

Set of atoms in the unit cell related by symmetry with the magnetic atom Ni1_3:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.37500	0.00000	0.12500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(0,1/4,3/4) + set click here to show and hide
2	0.37500	0.25000	0.87500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(0,1/2,1/2) + set click here to show and hide
3	0.37500	0.50000	0.62500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(0,3/4,1/4) + set click here to show and hide
4	0.37500	0.75000	0.37500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/4,0,3/4) + set click here to show and hide
5	0.62500	0.00000	0.87500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/4,1/4,1/2) + set click here to show and hide
6	0.62500	0.25000	0.62500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/4,1/2,1/4) + set click here to show and hide
7	0.62500	0.50000	0.37500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/4,3/4,0) + set click here to show and hide
8	0.62500	0.75000	0.12500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/2,0,1/2) + set click here to show and hide
9	0.87500	0.00000	0.62500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/2,1/4,1/4) + set click here to show and hide
10	0.87500	0.25000	0.37500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/2,1/2,0) + set click here to show and hide
11	0.87500	0.50000	0.12500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(1/2,3/4,3/4) + set click here to show and hide
12	0.87500	0.75000	0.87500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(3/4,0,1/4) + set click here to show and hide
13	0.12500	0.00000	0.37500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(3/4,1/4,0) + set click here to show and hide
14	0.12500	0.25000	0.12500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(3/4,1/2,3/4) + set click here to show and hide
15	0.12500	0.50000	0.87500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(3/4,3/4,1/2) + set click here to show and hide
16	0.12500	0.75000	0.62500	m_x,0,-m_x	0.92000	0.00000	-0.92000
(0,3/4,3/4)' + set click here to show and hide
17	0.37500	0.75000	0.87500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(0,0,1/2)' + set click here to show and hide
18	0.37500	0.00000	0.62500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(0,1/4,1/4)' + set click here to show and hide
19	0.37500	0.25000	0.37500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(0,1/2,0)' + set click here to show and hide
20	0.37500	0.50000	0.12500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/4,3/4,1/2)' + set click here to show and hide
21	0.62500	0.75000	0.62500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/4,0,1/4)' + set click here to show and hide
22	0.62500	0.00000	0.37500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/4,1/4,0)' + set click here to show and hide
23	0.62500	0.25000	0.12500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/4,1/2,3/4)' + set click here to show and hide
24	0.62500	0.50000	0.87500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/2,3/4,1/4)' + set click here to show and hide
25	0.87500	0.75000	0.37500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/2,0,0)' + set click here to show and hide
26	0.87500	0.00000	0.12500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/2,1/4,3/4)' + set click here to show and hide
27	0.87500	0.25000	0.87500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(1/2,1/2,1/2)' + set click here to show and hide
28	0.87500	0.50000	0.62500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(3/4,3/4,0)' + set click here to show and hide
29	0.12500	0.75000	0.12500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(3/4,0,3/4)' + set click here to show and hide
30	0.12500	0.00000	0.87500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(3/4,1/4,1/2)' + set click here to show and hide
31	0.12500	0.25000	0.62500	-m_x,0,m_x	-0.92000	0.00000	0.92000
(3/4,1/2,1/4)' + set click here to show and hide
32	0.12500	0.50000	0.37500	-m_x,0,m_x	-0.92000	0.00000	0.92000

[Hide]

label	dim. full irrep	dim. small irrep	direction	action	number of modes
mL3+	8	2	special	primary	3
mL1+	4	1		secondary	1

MAGNDATA: A Collection of magnetic structures with portable cif-type files

GeNi₂O₄ (#1.560)

MAGNDATA: A Collection of magnetic structures with portable cif-type files

GeNi2O4 (#1.560)

GeNi₂O₄ (#1.560)
